Outdoor Digital Display Screens Led Led Panel 4x3m Outdoor Rental P3.9 Led Display Panel

More Features & More Advantages
* 3 times aging process
* Salty spray test, high voltage test, varying temperature test, waterproof test, vibration test
* Long service time and low attenuation by applying dual channels for heat dissipation
* High protection grade of IP65 achieved by patented mask design with waterproof and dustproof function
* No deformation under sunlight by the use of Anti-UV module mask, Anti-Oxidation module frame with protection from deformation

Speification of Outdoor Rental Led Display:

Module Number	PH2.604	PH2.976	PH3.91	PH4.81
Pixel Pitch	2.604mm	2.976mm	3.91mm	4.81mm
Physical Density	147456 pixels/m2	112896 pixels/m2	65536 pixels/m2	43264 pixels/m2
Led Arrangement	3 in 1SMD	3 in 1 SMD	3 in 1SMD	3 in 1 SMD
Module Resolution	96*96 pixels	84*84 pixels	64*64 pixels	52*52 pixels
Module Dimensions	250*250 mm	250*250mm	250*250 mm	250*250mm
Cabinet Resolution	192*192 pixels	168*168 pixel	128*128 pixels	104*104 pixel
Cabinet Dimensions	500*500 mm	500*500 mm	500*500 mm	500*500 mm
Cabinet Weight	7.5kg	7.5kg	7.5kg	7.5kg
Brightness	≥5000 nits	≥5000 nits	≥5000 nits	≥5000 nits
Max Power Consumption	180w/panel	180w/panel	180w/panel	132w/panel
Ave Power Consumption	60w/panel	60w/panel	60w/panel	44w/panel
Viewing Angle	160°(W) 160°(H)	160°(W) 160°(H)	160°(W) 160°(H)	160°(W) 160°(H)
Operating Power source	110-240V AC 50-60Hz	110-240V AC 50-60Hz	110-240V AC 50-60Hz	110-240V AC 50-60Hz
Operating Temperature	-20℃～+50℃	-20℃～+50℃	-20℃～+50℃	-20℃～+50℃
Refresh Rate	3840Hz	3840Hz	3840Hz	3840Hz
IP Rating	IP65	IP65	IP65	IP65
Signal Input Source	Composite, S-video, Component, HDMI, SDI, HD, VGA, DVI	Composite, S-video, Component, HDMI, SDI, HD, VGA, DVI	Composite, S-video, Component, HDMI, SDI, HD, VGA, DVI	Composite, S-video, Component, HDMI, SDI, HD, VGA, DVI
Verification	ETL, FCC, CCC, RoHS,CE	ETL, FCC, CCC, RoHS,CE	ETL, FCC, CCC, RoHS,CE	ETL, FCC, CCC, RoHS,CE

Curved Installation

High Precision Curve Lock design (-10° to +10°) is adopted to solve the problem that the old curved lock is difficult to use
before. Rotational control, more accurate, easy to use and quickly adjust curve degree.

RFQ of Outdoor rental led screen:

Q1:LED display models are generally expressed in PX, such as P2 P3 P4.....P8, P10, what does this mean? A: P3 P4.....P8,P10 means that the pixel pitch is 3mm 4mm....10mm, which determines resolution of a display .Pixel pitch is smaller, led display resolution is higher.

Q2:What pixel pitch should I choose on my display? A:Using the PX screen, it is determined mainly by the viewing distance, the size of the display screen, the desired effect and the customer budget.

Q3: To order a display ,What kind of information do I have to offer you? A:You should provide width/height of the display, the main use, the viewing distance, the scene photos, special requirements,then I can provide you with a detailed list of quotations.

Q4:How to install? A:Free of charge to provide detailed steel structure drawings and installation guidance and wiring diagram,free remote debugging. We can also send our engineers to the site to guide the installation if needed.

Q5:What about your quality? A:The quality of our display is excellent. We use the materials of high quality suppliers in the world,strictly control the production process, and pass the multiple quality inspection to ensure that every product is qualified.

Q6:What about the warranty? A:Two year warranty

Q7:What about the lead time? A:Orders less than 50 square meter display, lead time is 15 working days. Q8:Can I order a sample? A:Yes,We welcome customers to order samples to check our product quality of our products and service.
