P6.67 P8 P10 outdoor full color Court LED full-color screen 960x960mm blue court LED fence screen

Product Description

Outdoor Fixed LED Screen Specification

Pixe Pictch

4mm

5mm

6mm

8mm

Led encapsulation

SMD1921

SMD2727

SMD2727

SMD2727/SMD3535

Scan Mode

1/8 Scan

1/8 Scan

1/8 Scan

1/4 Scan

Pixe Per Sq.m

62,500 Pixel

40,000 Pixel

27,777 Pixel

15,625 Pixel

Module Size(W*H)

256*128mm

320*160mm

192*192mm

320*320mm/320*160mm

Cabinet Size(W*H*D)

1024*768mm

960*960mm

960*960mm

960*960mm

Cabinet Weight

45KG/Pieces

40KG/Pieces

40KG/Pieces

45KG/Pieces

Max Power Consumption

900Watt/㎡

900Watt/㎡

900Watt/㎡

900Watt/㎡

Brightness(Nits/㎡)

5000Nits

5500Nits

6000Nits

6500Nits

Maintenance methods

Rear/Front Serviceable

Cabinet Material

Steel/Aluminun Option

Refresh Rate

1920hz-3840hz

Color temperature

6500K ±500(Adjustable)

Grey Scale

14-16bits

Average Power Consumption

500Watt/㎡

IP Protection

IP65 Front/Rear

Operating Temperature

-20°C to 50°C

Working Voltage

100-240Volt(50-60hz)

Installation Process

Customer Cases

Packing & Delivery

8 in one flight case (88kg)

Company Profile

Shenzhen Kingvisionled Optoelectronics Co.Ltd is a manufacturer which have lead-edge technologies in solving problems of led field.Jinhe was established in 2006 Shenzhen, with a plant area of 10,000 square meters, stuffs is 300 members,.At the end of 2012,the producing capability was reached up to 10000sq.m per month.It become the leading manufacturer in the LED industry soon.It's one of the fastest growing companies in China.
Stable-quality is the foundation that makes us survive,high quality products and good sales performance is the supporter that drives us moving,innovation and invention is the guarantee that makes the product competitively,talent is a big power that pushesthe company become stronger and bigger.Widely using automatic machine production line,it is one of the companies which has themost automated stage of production and have completely equipment and facilities.Our products have passed International Environmental Certification of ROHS,CE,and CCC.That makes the production internationalized.Our products have been sold to morethan 60 countries and areas in the world.

FAQ

Q1: What is the shipping way?
A1: For the mass order ( fit for a container), we do shipment by Sea and for others usually by express or airline

Q2: Can a sample order be placed before the mass production?
A2: Yes, we acceptable sample orders led display, please let us know your detail request then we will send you the sample asap
for confirmation.

Q3: Can a sample product be free?
A3: We offer free sample for some models, please advise what you need to see if we have available free samples here to be sent

Q4: Can a led display be any size?
A4: Nope, according the led module size and cabient size, such as p4.81mm is 500x500mm for smallest unit.

Our Service

1)Training after order
After the order is placed, a processional training will be offered, including software use, operate safety,

maintain equipment

2) Installation and debugging
Wecould send professionals to conduct on site installation and debugging in strict accordance with the

requirements of the schemes and original manual.

3) Warranty
Warranty: 3 years warranty, lifetime maintenance
Equip with free spare parts. The first 2 years after shipment, we will be responsible for free maintenance

if any problem causedby quality itself. While you should take the cost of the freight to us. After 2 years,

service is still available, but would charge for labor, material and freight cost that generates.

4) Maintenance
Maintenance principles: response in time, solve problems asap and ensure the use.
Maintenance period: In the maintenance period of the led display body, free of all maintenance charges
After maintenance period, only charge the material cost and labor cost.
