Model Number : | P5 |
Brand Name : | King VisionLed |
Supply Ability : | 1000 Square Meter/Square Meters per Week |
Price : | $1,520.00/Square Meters 6-49 Square Meters |
Certification : | CE, ROHS, ISO 9001, UL |
Payment Terms : | D/A, D/P, T/T, Western Union, L/C, MoneyGram |
Delivery Time : | 15 working days |
Outdoor Street Advertising Light Pole Led Display Screen Wifi 3g Intelligent Centralized Management
Describe of Advertising LED Display Screen:
(1) Super light design ensure the cabinet easy to be installed and
disassembled.
(2) High brightness meet the needs of various application
environments.
(3) Energy saveing design and good performance in color uniformity.
(4) Superb workmanship to ensure every processing details.
(5) Environmental raw material (LED chips, mask, glue, and steel
cabinets).
Advertising LED Display Screen | P4 | P5 | P6 | P8 | P10 |
Pixel Pitch(mm) | 4 | 5 | 6.67 | 8 | 10 |
LED Chips | SMD1921 | SMD2525 | SMD3535 | SMD3535 | SMD3535 |
Pixel density(dots/m2) | 62500 | 40000 | 22477 | 15625 | 10000 |
Driving Method | 1/10 scanning | 1/8 scanning | 1/6 scanning | 1/5 scanning | 1/2 scanning |
Module Size(mm) | 320*160 | 320*160 | 320*160 | 320*160 | 320*160 |
Module Resolution | 80*40 | 64*32 | 48*24 | 40*20 | 32*16 |
Cabinet Size( W*L mm) | 960*960 | 960*960 | 960*960 | 960*960 | 960*960 |
Cabinet Material | Magnesium Alloy | Magnesium Alloy | Magnesium Alloy | Magnesium Alloy | Magnesium Alloy |
Cabinet Weight( Kg/m2 ) | 35 | 35 | 35 | 35 | 35 |
Max.Consumption(W/m2) | 800 | 800 | 800 | 800 | 800 |
Ave.Consumption(W/m2) | 350 | 350 | 350 | 350 | 350 |
Brightness( Nits ) | ≥5500 | ≥5000 | ≥5500 | ≥5800 | ≥6000 |
Viewing Angle (Vertical / Horizontal) | 120° / 120° | 120° / 120° | 120° / 120° | 12 F0° / 120° | 120° / 120° |
Refresh Rate | ≥1920Hz | ≥1920Hz | ≥1920Hz | ≥1920Hz | ≥1920Hz |
IP Level | IP65 | IP65 | IP65 | IP65 | IP65 |
![]() |
