Model Number : | P4 |
Brand Name : | King VisionLed |
Supply Ability : | 1000 Square Meter/Square Meters per Week |
Price : | $608.00/Square Meters 6-49 Square Meters |
Certification : | CE, ROHS, ISO 9001, UL |
Payment Terms : | D/A, D/P, T/T, Western Union, L/C, MoneyGram |
Delivery Time : | 15 working days |
P4 P6 P8 Customized Easy Installation Outdoor Big Commercial Advertising Dooh Display
Introduction OF Big Commercial Advertising Dooh Display:
P8 outdoor led screen adopts physical and virtual pixel technology
which makes the picture more clear and vivid, no flicker and blind
dots. The screen is manufactured in a waterproof and dustproof
design so it can work very well in rain and sunshine. It can be
assembled and disassembled very easy, and it is an ideal product
for any kind advertisements.
It characterized by perfect vivid image, super brightness, high refresh rate, long life span and stable work, and waterproof, etc.
It is widely used in advertising, sports, industrial enterprise, transportation, stations, terminals, airports, construction, education system and other public places.
Commercial Advertising Dooh Display | P4 | P5 | P6 | P8 | P10 |
Pixel Pitch(mm) | 4 | 5 | 6.67 | 8 | 10 |
LED Chips | SMD1921 | SMD2525 | SMD3535 | SMD3535 | SMD3535 |
Pixel density(dots/m2) | 62500 | 40000 | 22477 | 15625 | 10000 |
Driving Method | 1/10 scanning | 1/8 scanning | 1/6 scanning | 1/5 scanning | 1/2 scanning |
Module Size(mm) | 320*160 | 320*160 | 320*160 | 320*160 | 320*160 |
Module Resolution | 80*40 | 64*32 | 48*24 | 40*20 | 32*16 |
Cabinet Size( W*L mm) | 960*960 | 960*960 | 960*960 | 960*960 | 960*960 |
Cabinet Material | Magnesium Alloy | Magnesium Alloy | Magnesium Alloy | Magnesium Alloy | Magnesium Alloy |
Cabinet Weight( Kg/m2 ) | 35 | 35 | 35 | 35 | 35 |
Max.Consumption(W/m2) | 800 | 800 | 800 | 800 | 800 |
Ave.Consumption(W/m2) | 350 | 350 | 350 | 350 | 350 |
Brightness( Nits ) | ≥5500 | ≥5000 | ≥5500 | ≥5800 | ≥6000 |
Viewing Angle (Vertical / Horizontal) | 120° / 120° | 120° / 120° | 120° / 120° | 120° / 120° | 120° / 120° |
Refresh Rate | ≥1920Hz | ≥1920Hz | ≥1920Hz | ≥1920Hz | ≥1920Hz |
IP Level | IP65 | IP65 | IP65 | IP65 | IP65 |
![]() |
