Glass Wall LED Curtain Screen Working Temperature -10~40℃ Easy Installation Display

Ask Lasest Price
Model Number :	P3.91-7.8
Brand Name :	King VisionLed
Supply Ability :	1000 Square Meter/Square Meters per Week
Price :	$685.00/Square Meters 6-49 Square Meters
Certification :	CE, CCC, Rohs, FCC ISO
Payment Terms :	L/C, D/A, D/P, T/T, Western Union
Delivery Time :	15 working days

Add to Cart

Product Details
Company Profile

Glass Wall LED Curtain Screen Working Temperature -10~40℃ Easy Installation Display

LED Curtain Screen Detail:

Transparent LED display is a new type of display screen, which has a transparent LED on the front instead of glass en exhibits the product inside. This transparent display attracts customers by setting the exhibited product in vivid contrast to its background of digital contents.

With 70%-95% transparence, the screens has made a super transparent LED screen. The panel thickness is just 10mm, so the LED unit panel can be installed from behind the glass and perfectly integrated with the glass. The unit size can be customized according to the size of the glass and has little influence on the light-gathering and transparence of the glass wall. It’s also easy to install and maintain. With all these advantages, the super transparent LED screen is very suitable in the field of architectural media.

LED Curtain Screen Parameters
Model	LW-T3	LW-T7	LW-T10
Pixel Pitch(mm)	3.9 × 7.8	7.8 × 7.8	10.4 × 10.4
Module size(mm)	1000 × 500	1000 × 500	1000 × 500
Pixel(pixels/pcs)	256 × 64	128 × 64	96 × 48
Pixel density (pixels/m2)	32768	16384	9216
Pixel configuration	SMD 3in1	SMD 3in1	SMD 3in1
Video frame rate
Brightness(cd/m2)	4000	2500	2500
Horizontal viewing angle	160°	160°	160°
Vertical viewing angle	120°	120°	120°
transparency	85%	85%	87%
Grayscale	16384	16384	16384
Driving method	1/8 scan	1/8 scan	1/6 scan
Display refresh rate	3840	3840	3840
Video frame rate	60	60	60
Operation state
Input power(max)(W/m2)	400	400	400
Input power(nor)(W/m2)	200	150	100
Input voltage (V)	100 ~ 240V AC, 47 ~ 63Hz
Performance temp	-20 ~ 50ºC
Storage temp	-40 ~ 80ºC
Humidity operating	10%~90%RH
Lifetime(hours)	≥10000
Lifespan (hours)	100000
Discrete out of control	≤0.0001,
Continuous out of control	0
Scotoma rate	≤0.0001,
Protect (Front/Reverse)	IP42
Product features
Installation	Lifting / Vertical loading
Border bevel	45°
Arc splicing	≥90°
weight(kg/m2)	10
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.

Glass Wall LED Curtain Screen Working Temperature -10~40℃ Easy Installation Display

LED Curtain Screen of Detail:

This design greatly decreases the structural unit’s blocks to the view, at the same time greatly increases the transparence of the glass wall. When the audiences stand in an idea position, the super transparent LED screen can create a special displaying effect– to the audiences the pictures appear to float on the glass wall. If you display advertisements on the super transparent LED screen, you can get rid of the unnecessary bottom color ,and change the color to dark which don’t give off light when the super transparent LED screen is played, just like it’s disappearing, thus the screen only displays the needed content. This playing method can greatly reduce light pollution and energy consumption, which is above 30% lower than the common LED screens.
