Small Pitch 8K LED Video Wall Display P1.8mm P2.5 Rich Content 800
CD/Sqm Flat
8K LED Video Wall Product Description
1. Rich experience: established in 2007; familiar with technical
and material about LED display and LED light.
2. Absolute OEM service: providing the most suitable solution for
you according to your different demands (such as quality, price and
etc.). At least 3 different types in one material are provided for
your choice , and with the lowest-cost custom service.
3. Powerful R&D ability: excellent engineers are constantly
developing new products and improving them.
4. Good quality: stable performance .
5. Thoughtful service: we always serve you heart and soul, striving
to make our products meet your demands in maximum degree.
6. We guarantee all our LED products for 2 years and provide
lifetime maintenance charging only for raw materials. We provide an
excellent after-sale service, which contains free training, free
CAD drawings, for more convenience and free consultation lifetime,
and we will inspect our products which have been sold periodically.
4K 8K LED Video Wall of Technical Parameter
| Parameter | P1.875mm HD LED Screen | P2.5mm HD LED Video wall |
| Pixel Pitch | 1.875mm | 2.5mm |
| Pixel Configuration | SMD 3-IN-1 | SMD2121 3-IN-1 |
| Pixel Density | 284,089 dots/m² | 160,000 dots/m² |
| Module size | 240x240mm | 240x240mm |
| Cabinet Size | 480x480mmx57mm | 480x480mmx57mm |
| Panel Dimension (WxHxD) | 18.9''X18.9''X3'' | 18.9''X18.9''X3'' |
| Panel Material | Die-casting Aluminum | Die-casting Aluminum |
| Panel Weight | 4.9kg/panel (10.8lb/panel) | 6.8kg/panel (15lb/panel) |
| Refresh Rate | 1920Hz~3840Hz | 1920Hz~3840Hz |
| Brightness | 1000nits(Adjustable) | 1200nits(Adjustable) |
| Horizontal Viewing Angle(°) | 160 ° | 160 ° |
| Vertical Viewing Angle(°) | 160 ° | 160 ° |
| AC Power Input(V) | AC110V~ 220V ±10% | AC110V~ 220V ±10% |
| AC Power Frequency(Hz) | 50 ~ 60 Hz | 50 ~ 60 Hz |
| Max. Power(W/m²) | 565 W/m² | 520 W/m² |
| Avg. Power(W/m²) | 189 W/m² | 170 W/m² |
| Storage/Operating Humidity(RH ) | 10% ~ 90%RH | 10% ~ 90%RH |
| IP Rating(IP ) | IP30 / IP30 | IP30 / IP30 |
| Lifetime Typical Value(Hrs) | 100,000 Hrs | 100,000 Hrs |
| Installation Type | Front&Rear installation | Front&Rear installation |
| Maintenance Method | Front&Rear Access Maintenance | Front&Rear Access Maintenance |
Product Details & Application
1.Magnetic Module with frame-sharing 480x480mm die-casting aluminum
cabinets
2. Friendly Cabinet design with comfortable rounded corner
handle,heat emission holes,signal indicator testing button,OEM
Label, Anti-collision corner,Hidden cables design and front
maintenance tool design.
3.Free-structure Install, flexible for wall mounted fixed and
saving installation cost and space
4.Wide application indoor stage rental or indoor advertising or
presentation
Our Services of 4K 8K LED Video WALL
What is the payment method?
We support a variety of payment methods, the most common is the TT;
How about your production ability?
We have 10 production lines with all series of automatic production
machines. Monthly production ability: 200,000pcs of led modules and
4,000sqm of assembled led displays;
What's the controlling system?
Our standard controlling system for this model is Linsn/ Novastar.
Also support other controlling system,like HD,Xixun,TF, Colorlight,
etc;
