Indoor Fixed Slim Series 250x750mm/250x1000mm Cabinet Easy To Bulid
Any Screen Size
Alternative Cabinet Size Options
● 250x750mm and 250x1000mm cabinet could
be easy to bulid any screen size for various project
Ultra Slim and Light Weight
● Cabinet weight 4kg only, easy to move, easy to install
● Cabinet thickness 40mm only, slim design,
save installation structure, save installation space
● Die casting cabinet, higher splicing preciseness, better flatness
| Pixel Pitch(mm) | P1.953 | P2.604 | P2.976 | P3.91 | P4.81 |
| Pixel Density(dot/m2) | 262,144 | 147,456 | 112,896 | 65,536 | 43,264 |
| LED Type | SMD1515 | SMD1515 | SMD2020 | SMD2020 | SMD2020 |
| Module Size(mm) | 250*250 | 250*250 | 250*250 | 250*250 | 250*250 |
| Cabinet Size (mm) |
1,000*250*40mm 750*250*40mm
|
1,000*250*40mm 750*250*40mm
|
1,000*250*40mm 750*250*40mm
|
1,000*250*40mm 750*250*40mm
|
1,000*250*40mm 750*250*40mm
|
| Cabinet Weight(kg) |
5.2kgs 4kgs
|
5.2kgs 4kgs
|
5.2kgs 4kgs
|
5.2kgs 4kgs
|
5.2kgs 4kgs
|
| Cabinet Resolution(px*px) |
512*128 384*128
|
384*96 288*96
|
336*84 252*84
|
256*64 192*64
|
208*52 156*52
|
| Maintenance way | Front & Rear | Front & Rear | Front & Rear | Front & Rear | Front & Rear |
| Horizontal/Vertical Viewing Angle | 140 °/140 ° | 140 °/140 ° | 140 °/140 ° | 140 °/140 ° | 140 °/140 ° |
| Brightness(cd/m2) | 1,000nits | 1,000nits | 1,000nits | 1,000nits | 1,000nits |
| Gray Scale | 16bit | 16bit | 16bit | 16bit | 16bit |
| Refresh Rate | 3,840hz | 3,840hz | 3,840hz | 3,840hz | 3,840hz |
| Scan Way | 1/32 | 1/32 | 1/28 | 1/16 | 1/13 |
| Max/Ave Power Consumption Consumption | 680/230w/m2 | 680/230w/m2 | 680/230w/m2 | 680/230w/m2 | 680/230w/m2 |
| Input Voltage(AC) | 100-240V | 100-240V | 100-240V | 100-240V | 100-240V |
| Ingress Protection | IP31 | IP31 | IP31 | IP31 | IP31 |
| Working Environment | Indoor | Indoor | Indoor | Indoor | Indoor |
| Life Span | >100,000hours | >100,000hours | >100,000hours | >100,000hours | >100,000hours |
| MTBF | >10,000hours | >10,000hours | >10,000hours | >10,000hours | >10,000hours |
Indoor Led Video Wall FAQ:
Q1: Is it OK to print my logo on the screen?
Of course, please inform us formally before our production.
Q2: How can you ensure the led display product quality?
All kinds of our screens have to do the aging test before leaving
factory. And we also have waterproof test and shaking test to
ensure the high-end level product quality.
Q3: Can I have a sample order of LED display screen?
Yes, we welcome sample order to test and check quality. Both for
LED module or a whole screen.
Q4: How to deal with the faulty?
Firstly, our products are produced in strict quality control system
and the defective rate will be less than 0.2%. Secondly, during the
guarantee period, we will repair them and resend them to you or we
can discuss the solution including re-call according to real
situation.
